Lightweight system with exceptional low frequency passive vibration isolation.

TableTop CSP®, Series 66

TableTop CSP®, Series 66

High-Performance Vibration Isolation System with Compact Sub-Hertz Pendulum Technology
Lightweight system with exceptional low frequency passive vibration isolation.

Benefits

  • Self-leveling design with height control valves
  • Electropolished stainless steel chassis with powder finish steel top plate
  • Incorporates patented CSP isolator design
  • Lightweight, low-profile

Features

  • Exceptional passivevibration isolation, comparable to our full-size industry standard
  • 63-500 Series Tables
  • Lightweight, Compact Design (less than 50 lbs) is easily portable
TableTop CSP®, Series 66

Images and Text Copyright TMC, reprinted with permission.

Buy Now
Brochure
Manual

Specifications

Net Load Capacity
150 lbs, 67 kg

Facilities Required
80 psi air or nitrogen

Finish
Electropolished Stainless Steel Sides and Base. Textured Powder Coat Carbon Steel Top Plate

Dimensions
18(w) x 20(d) x 3″(h)
(458 x 508 x 76mm)

Weight
50 lbs (22kg)

Nikon TE-2000 on TableTop™ CSP®

TableTop CSP®, Series 66, Nikon

Photo courtesy of Micro Video Instruments
